KYOCERA AVX 9286-250 Reduced Junction Box Connectors expand on the 9286 poke-home discrete wire-to-wire family of connectors in a smaller package size. These connectors electrically connect each of the inserted wires together, similar to a branch or splitter application but with multiple outputs. An active stainless steel spring contact eliminates the need for push button activation to insert and remove wires. KYOCERA AVX 9286-250 contacts provide maximum wire retention across a broad range of solid and stranded wire gauges, making this connector series highly versatile in field installations. These poke-home WTW connectors are rated for 300VAC and operating temperatures spanning -40°C to +130°C. The connectors are 4mm high and 16mm long.
Simple strip and poke-home wire insertion with a twist and pull wire extraction
High spring force stainless steel contact maximizes cost, strength, and flexibility
Accepts 24AWG to 18AWG solid and stranded wires
Expanded size offering to allow up to 8 wires to be connected together
Industrial machine controls
300VAC voltage rating
-40°C to +130°C operating temperature range
4A to 8A maximum current range
UL 94V-0, glass-filled nylon 46 insulator material
ø2.10mm maximum insulation diameter
Copper alloy fixed contact material
Stainless steel flexing contact
Tin-over-nickel fixed contact plating
