Amphenol RF Mini-SMB Cable Assemblies

Amphenol RF Mini-SMB Cable Assemblies feature a reduced housing that provides circuit miniaturization and efficient space utilization. They perform from DC to 4GHz with 50Ω or 75Ω impedance. These connectors offer a snap-on interface for ease of use and quick installation. SMB assemblies are offered in a variety of configurations and are dimensioned in metric and imperial lengths. Amphenol RF SMB Cable Assemblies are built in accordance with the requirements of MIL-C-39012 and the interface is in compliance with MIL-STD 348. Applications include telecommunications, switching equipment, and networking systems.

Features

  • Reduced housing provides circuit miniaturization and efficient space utilization
  • Broadband performance with low reflection DC to 4GHz
  • 50Ω or 75Ω impedance
  • Push-on and snap-on mating styles for quick installation
  • Accommodates a wide range of RG flexible coaxial cables

Applications

  • Telecommunications
  • Switching equipment
  • Networking systems
