Abracon APARM2504-SG3 Multiband GNSS Dielectric Antenna

Abracon APARM2504-SG3 Multiband GNSS Dielectric Antenna is a patch antenna with GPS/GLONASS/BeiDou/Galileo. The compact (25.1mm x 25.1mm x 4.0mm) antenna features low VSWR of 1.8, RHCP polarization, GPS gain of 1.5dBi; GLONASS 3.5dBi; and BeiDou 2.5dBi. The antenna frequency range is 1575.42 ± 1.023 GPS; 1602 ± 5 GLONASS; 1561.098 ± 2.046 BeiDou; and 1575.42 ± 1.023 Galileo. Abracon APARM2504-SG3 Multiband GNSS Dielectric Antenna applications include IoT, M2M, remote technology monitoring, geofencing, navigation, surveying and mapping systems, logistics, and automotive.

Features

  • Multiband GNSS patch with GPS/GLONASS/BeiDou/Galileo
  • 1.8 VSWR
  • RHCP polarization
  • 25.1mm x 25.1mm x 4.0mm
  • Gain of:
    • GPS: 1.5dBi
    • GLONASS: 3.5dBi
    • BeiDou: 2.5dBi

Applications

  • GPS/GLONASS/BeiDou/Galileo applications
  • IoT
  • M2M
  • Remote technology monitoring
  • Geofencing
  • Navigation
  • Surveying and mapping systems
  • Logistics
  • Automotive
Published: 2019-08-01 | Updated: 2022-03-10
